-Rod End Supply 4130 Male Heim, 1/2x1/2-20 LH - XML8
Manufacturer Part Number: XML8

-Rod End Supply 4130 Male Heim, 1/2x1/2-20 LH - XML8

https://www.hoosiermidatlantic.com/web/image/product.template/62654/image_1920?unique=94adeda

Rod End Supply 4130 Male Heim, 1/2x1/2-20 LH - XML8

$ 21.99 21.99 USD $ 21.99

$ 21.99

Not Available For Sale

This combination does not exist.

Contact Us

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

Share

Rod End Supply 4130 Male Heim, 1/2x1/2-20 LH - XML8

XM, XF CHROMOLY STEEL SELF LUBRICATING & SELF SEALING NYLAFIBER MATRIX RACE

RES PART NO. BORE X THD. SIZE REF. B DIA. +.0015 -.0005 D DIA. +.010 -.010 W WIDTH + .000 - .005 T WIDTH + .005  - .005 BALL DIA.
REF.		 AM LGTH. -.015 +.015 Af LGTH. -.015 +.015 N THD. UNF. 3A-2B CM LGTH. +.062 -.031 CF LGTH. +0.62 -.031 E DIA. -.010 +.010 F WRENCH FLAT +.010 -.010 a MIS. ANG. REF. ULT. STATIC RADIAL LOAD(LBS.) APPROX. WEIGHT
(LBS.)
XM 3 3/16x10-32 .1900 .625 .312 .250 .437 1.250 - 10-32 .750 - - - 13 2851 .03
XF 3 3/16x10-32 .1900 .625 .312 .250 .437 - 1.062 10-32 - .562 .406 .312 13 3733 .04
XM 4 1/4x1/4-28 .2500 .750 .375 .281 .500 1.562 - 1/4-28 1.000 - - - 16 5260 .04
XF 4 1/4x1/4-28 .2500 .750 .375 .281 .500 - 1.312 1/4-28 - .750 .469 .375 16 6190 .06
XM 5 5/16x5/16-24 .3125 .875 .437 .344 .625 1.875 - 5/16-24 1.250 - - - 14 7639 .07
XF 5 5/16x5/16-24 .3125 .875 .437 .344 .625 - 1.375 5/16-24 - .750 .500 .437 14 7639 .09
XM 6 3/8x2/8-24 .3750 1.000 .500 .406 .719 1.938 - 3/8-24 1.250 - - - 12 9544 .11
XF 6 3/8x3/8-24 .3750 1.000 .500 .406 .719 - 1.625 3/8-24 - .937 .687 .562 12 9544 .15
XM 7 7/16x7/16-20 .4375 1.125 .562 .437 .812 2.125 - 7/16-20 1.375 - - - 14 10285 .16
XF 7 7/16x7/16-20 .4375 1.125 .562 .437 .812 - 1.812 7/16-20 - 1.062 .750 .625 14 10285 .20
XM 8 1/2x1/2-20 .5000 1.312 .625 .500 .937 2.438 - 1/2-20 1.500 - - - 12 16238 .25
XF 8 1/2x1/2-20 .5000 1.312 .625 .500 .937 - 2.125 1/2-20 - 1.187 .875 .750 12 16238 .33
XM 10 5/8x5/8-18 .6250 1.500 .750 .562 1.125 2.625 - 5/8-18 1.625 - - - 16 17995 .38
XF 10 5/16x5/8-18 .6250 1.500 .750 .562 1.125 - 2.500 5/8-18 - 1.500 1.000 .875 16 17995 .48
XM 12 3/4x3/4-16 .7500 1.750 .875 .687 1.312 2.875 - 3/4-16 1.750 - - - 14 28081 .60
XF 12 3/4x3/4-16 .7500 1.750 .875 .687 1.312 - 2.875 3/4-16 - 1.750 1.125 1.000 14 28081 .72
XM 14 7/8x7/8-14 .8750 2.000 .875 .765 1.375 3.375 - 7/8-14 2.000 - - - 7 45051 .91
XF 14 7/8x7/8-14 .8750 2.000 .875 .765 1.375 - 3.375 7/8-14 - 1.875 1.300 1.125 7 45051 .93
XM 16-1 1x1-14 1.000 2.750 1.375 1.015 1.875 4.125 - 1-14 2.125 - - - 17 76200 2.41
XF 16-1 1x1-14 1.000 2.750 1.375 1.015 1.875 - 4.125 1-14 - 2.125 1.625 1.500 17 76200 2.45
